Bottle Rinser - Semi-Automatic (2 or 4 Nozzle)

BOTTLE RINSER - SEMI-AUTOMATIC (2 OR 4 NOZZLE)

An integrated solution to rinse or sanitize bottles and jars before filling. This machine is designed for the internal cleaning and rinsing of bottles or jars by means of water and or a disinfectant/sanitizer product. This machine allows you to easily clean bottles before filling them with your product to guarantee product quality. The machine is entirely made of stainless steel.

This semi-automatic bottle rinsing machine from Tenco allows you to clean and or sanitize the internal surface of bottles before filling them. This version is equipped with a pump and recycle reservoir for rinsing with only water or with a disinfecting/sanitizing product where the solution is pumped into the bottle(s) through the nozzles using pressure after going through the optional on board filter.

Like all other Tenco products this Italian built Semi-Automatic Bottle Rinser is extremely well designed and built with tremendous care to fit, finish for ease of operation and built entirely from AISI 304 Stainless Steel for easy cleaning and many years of dependable use.

Click Here to Watch A Product Demo Video

Details:

• Semi-automatic bottle rinsing machine with two nozzles or four nozzles
• Outfitted with Nozzles to fit bottle opening diameters of 12.5mm to 26mm with minimum height of 150mm (Nozzles for smaller or larger bottles available upon request)
• Recirculation Pump and reservoir tank - 110 Volt 60hz 9 Amp pump motor that comes with water proof Quick Connect for you to Hard Wire to or add your own power cord
• 25 micron filter for filtration of water/solution - (Included starting October 1, 2023)
• Pump head and impeller made of 304 stainless steel and will inclued stainlees reservoir tank
• Constructed from 304 Stainless Steel for easy cleaning and maintenance
• Volume - Up to 800 bottles per hour depending on operator skill level
• SEE TENCO's Water/Air Combo Semi-automatic bottle rinsing machine with nozzles for rinsing plus nozzles injecting gas for sparging or air for drying (common for cleaning bottles to be filled with oils)

• Injectors/nozzles for miniature bottles
• Injectors/nozzles for jars with larger openings
• We can also customize a four nozzle unit to sterilize with two nozzles and rinse with two nozzles that would include a split basin/pan
• We can also construct a high alcohol unit for use with a high alcohol content rinsing/sanitizing solution
• To NOT include pump and reservoir tank such that unit can be connected directly to plumbed/domestic water source
• Add fittings and hardware to provide option to connect directly to fresh/domestic water source and easily switch over to pull from reservoir tank
